Wall Thickness
SCH.10, 20, 30, 40, 80, 120, 160, STD, XS, XXS, and Solid Bore

Types
Welding Neck, Blind, Slip On, Threaded, Socket Weld, Lap Joint, Hanger, Reducing Cover, Orifice, Long Welding Neck, Swivel Ring, Spectacle Blind, Spade Blind, Spacer Ring, and Solid Slip On (Blind with HUB)

Range and Stock Available in Carbon Steel (A105N), Low Temperature (A350-LF2) and Stainless Steel (A182 F304/L & F316/L)
150# Raised Face 1/2" through 36"
300# Raised Face 1/2" through 36"
600# Raised Face/RTJ 1/2" through 24"
900# Raised Face/RTJ 1/2" through 24"
1500# Raised Face/RTJ 1/2" through 24"
2500# Raised Face/RTJ 1/2" through 24"
3000# RTJ 1.9/16" through 4.1/16"
5000# RTJ 1.9/16" through 4.1/16"


Materials Specifications Grades
Carbon Steel ASTM A105N
Low Temp
Carbon Steel
ASTM A350 LF2
LF3

High Yield
Carbon Steel

ASTM A694 F42
F52
F60
Alloy Steel ASTM A182 / A182M F1
F5
F9
F11/12
F22
Stainless Steel ASTM A182 / A182M F304/L
F316/L
F321

Note: If a material is not listed, it does not mean that it is unavailable.
