Butt-Weld Fittings
As per A.N.S.I B16.9/B16.28
| Wall Thickness |
|---|
|
SCH.10, 20, 30, 40, 60, 80, 100, 120, 160, STD, XS, and XXS |
| Range and Stock Available in Carbon Steel (WPB), Low Temperature (WPL6) and Stainless Steel (WP304/L, WP316/L) | |
|---|---|
|
Elbow 45 & 90 Degree Long Radius |
1/2″ through 42″ |
|
Elbow 90 Degree Short Radius |
1/2″ through 24″ |
|
180 Degree Return Bend Long & Short Radius |
1″ through 8″ |
|
Tee Equal and Reducing |
1/2″ through 42 “ |
|
Reducer Concentric and Eccentric |
3/4″ through 36″ |
|
Cap |
1/2″ through 42 “ |
| Materials | Specifications | Grades |
|---|---|---|
|
Carbon Steel |
ASTM A234 |
WPB |
|
Low Temp Carbon Steel |
ASTM A420 |
WPL6 |
|
WPL3 |
||
|
High Yield
Carbon Steel |
ASTM 860
(MSS-SP75) |
WPHY42 |
|
WPHY52 |
||
|
WPHY60 |
||
|
Alloy Steel |
ASTM 234 |
WP1 |
|
WP5 |
||
|
WP9 |
||
|
WP11/12 |
||
|
WP22 |
||
|
Stainless Steel |
ASTM A403 / A403M |
WP304/L |
|
WP316/L |
||
|
WP321 |
Note: If a material is not listed, it does not mean that it is unavailable.
